E3ISPM20000KPA 2000万 索尼IMX183 图谱 touptek

45M/IMX294(C)

1.4“ (18.93x13.00)

2.315x2.315

108mv with 1/30s

0.03mv with 1/30s

8.1@8176x5616

30.0@4088x2808

8.1@7408x5556

33.0@4088x2808

10.4@8176x4320

34.7@4096x2160

62.5@2048x1080

86.5@1344x720

1x1(3:2)

2x2(3:2)

1x1(4:3)

2x2(4:3)

1x1(17:9)

2x2(17:9)

3x3(17:9)

4x4(17:9)

0.1ms~15s

E3ISPM45000KPB

45M/IMX492(C,RS)

1.4“ (18.93x13.00)

2.315x2.315

108mv with 1/30s

0.03mv with 1/30s

8.1@8176x5616(C)

30.0@4080x2808(M)

8.1@7408x5556(C)

33.0@3696x2778(M)

10.4@8176x4320(C)

34.7@4096x2160(M)

62.5@2048x1080(M)

86.5@1344x720(M)

1x1(3:2)

2x2(3:2)

1x1(4:3)

2x2(4:3)

1x1(17:9)

2x2(17:9)

3x3(17:9)

4x4(17:9)

0.1ms~15s

E3ISPM32000KPA

32M/IMX294(C)

1.15“ (12.96x12.96)

2.315x2.315

108mv with 1/30s

0.03mv with 1/30s

8.1@5600x5600

30.0@2800x2800

30.0@1400x1400

1x1

2x2

4x4

0.1ms~15s

E3ISPM25000KPA

25M/IMX511(C)

1/2.3 “ (5.519x5.519)

1.12x1.12

96.3mv with 1/30s

0.1mv with 1/30s

12@4928x4928

46@2464x2464

100@1648x1648

1x1

2x2

3x3

0.013ms~15s

E3ISPM21000KPA

21M/IMX269(C)

4/3 “(17.4x13.0)

3.3 x3.3

399mv with 1/30s

0.1mv with 1/30s

17@5280x3954

17@3952x3952

56@2640x1976

67@1760x1316

192@584x438

1x1

1x1

2x2

3x3

9x9

0.1ms~15s

E3ISPM20400KPA

20.4M/IMX541(C,GS)

1.1 “(12.32x12.32)

2.74 x2.74

1574mv with 1/30s

0.15mv with 1/30s

17.5@4496x4496

64.4@2240x2240

64.4@1120x1120

1x1

2x2

4x4

0.03ms~15s

E3ISPM20000KPA

20M/IMX183(C,RS)

1 “(13.06x8.76)

2.4 x2.4

462mv with 1/30s

0.21mv with 1/30s

15@5440x3648

50@2736x1824

60@1824x1216

1x1

2x2

3x3

0.1ms~15s

E3ISPM20000KPC

20M/IMX183(C,RS)

1 “(13.06x8.76)

2.4 x2.4

462mv with 1/30s

0.21mv with 1/30s

20@5440x3648

48@2736x1824

58@1824x1216

1x1

2x2

3x3

0.1ms~15s

E3ISPM18000KPA

18M/SONY Special(C)

1/2.2 “(5.86x4.46)

1.2 x1.2

130mv with 1/30s

0.1mv with 1/30s

17@4880x3720

40@2448x1836

50@1728x1296

1x1

2x2

3x3

0.1ms~15s

E3ISPM15600KPA

15.6M/SONY Special (C)

1.1 “(13.0x13.0)

3.3 x3.3

399mv with 1/30s

0.1mv with 1/30s

17@3952x3952

56@1976x1976

67@1316x1316

1x1

2x2

3x3

0.1ms~15s

E3ISPM12400KPA

12.4M/IMX545(C,GS)

1/1.1 “(11.22x8.22)

2.74 x2.74

1337mv with 1/30s

0.15mv with 1/30s

28.2@4096x3000

100.9@2048x1500

100.9@1024x750

1x1

2x2

4x4

0.03ms~15s

E3ISPM12300KPA

12.3M/IMX304(C,GS)

1.1”(14.13x10.35)

3.45x3.45

1146mv with 1/30s

0.1mv with 1/30s

23.4@4096x3000

46.3@2048x1500

1x1

1x1

0.244ms~15s

E3ISPM12000KPA

12M/IMX226(C)

1/1.7“(7.40x5.55)

1.85x1.85

280mv with 1/30s

0.1mv with 1/30s

25@4000x3000

50@2048x1080

1x1

2x2

0.1ms~15s

E3ISPM12000KPB

12M/IMX577(C)

1/2“(6.29x4.71)

1.55x1.55

250mv with 1/30s

0.25mv with 1/30s

30@4056x3040

60@2028x1520

120@1014x760

1x1

2x2

4x4

0.1ms~5s

E3ISPM12000KPC

12M/IMX676(C)

1/1.6“(7.07x7.07)

2.0x2.0

3637mv with 12 bit converted value(HCG)

0.15mv with 1/30s

27@3536x3536

60@1768x1768

1x1

2x2

0.013ms~15s

E3ISPM09000KPA

9.0M/IMX305(C,GS)

1“ (14.13x7.45)

3.45x3.45

1146mv with 1/30s

0.15mv with 1/30s

34@4096x2160

60@2048x1080

1x1

1x1

0.1ms~15s

E3ISPM09000KPB

9.0M/IMX533(C)

1“ (11.31x11.28)

3.76x3.76

535mv with 1/30s

0.04mv with 1/30s

40@3008x3000

123@1488x1500

186@992x998

1x1

2x2

3x3

0.1ms~15s

E3ISPM08300KPA

8.3M/IMX274(C)

1/2.5”(6.22x3.50)

1.62x1.62

236mv with 1/30s

0.1mv with 1/30s

32@3840x2160

65@1920x1080

1x1

2x2

0.244ms~15s

E3ISPM08300KPB

8.3M/IMX334(C)

1/1.8”(7.68x4.32)

2.0x2.0

505mv with 1/30s

0.1mv with 1/30s

35@3840x2160

60@1920x1080

1x1

2x2

0.02ms~15s

E3ISPM08300KPC

8.3M/IMX485(C)

1/1.2”(11.14x6.26)

2.9x2.9

2188mv with 1/30s

0.15mv with 1/30s

45@3840x2160

70@1920x1080

1x1

2x2

0.02ms~15s

E3ISPM08300KPD

8.3M/IMX585(C)

1/1.2”(11.14x6.26)

2.9x2.9

5970(mV/lx/s)

0.13mv with 1/30s

45@3840x2160

70@1920x1080

1x1

2x2

0.02ms~15s

E3ISPM08300KPE

8.3M/IMX678(C)

1/1.8”(7.68x4.32)

2.0x2.0

3541(mV/lx/s)

0.15mv with 1/30s

45@3840x2160

70@1920x1080

1x1

2x2

0.02ms~15s

E3ISPM08000KPA

8.0M/IMX294(C)

1.15 “(13.00x13.00)

4.63 x4.63

419mv with 1/30s

0.12mv with 1/30s

30@2808x2808(14bit)

139@1392x1392

139@696x696

1x1

2x2

4x4

0.1ms~15s

E3ISPM06300KPA

6.3M/IMX178(C,RS)

1/1.8“ (7.37x4.92)

2.4x2.4

425mv with 1/30s

0.15mv with 1/30s

30@3072 x2048

38@1536x 1024

1x1

2x2

0.1ms~15s

E3ISPM06300KPB

6.3M/IMX178(C,RS)

1/1.8“ (7.37x4.92)

2.4x2.4

425mv with 1/30s

0.15mv with 1/30s

59@3072 x2048

59@1536x 1024

1x1

2x2

0.02ms~15s

E3ISPM05100KPA

5.1M/IMX547(C,GS)

1/1.8“ (6.71x5.61)

2.74x2.74

1337mv with 1/30s

0.15mv with 1/30s

63@2448x2048

208.4@1224x1024

1x1

2x2

0.03ms~15s

E3ISPM05000KPA

5.0M/IMX264(C, GS)

2/3” (8.45x7.07)

3.45x3.45

1146mv with 1/30s

0.15mv with 1/30s

35@2448x2048

50@1224x1024

1x1

1x1

0.1ms~15s

E3ISPM03100KPA

3.1M/IMX265(C, GS)

1/1.8“ (7.07x5.30)

3.45x3.45

1146mv with 1/30s

0.15mv with 1/30s

53@2048x1536

85@1024x768

1x1

1x1

0.1ms~15s

E3ISPM03100KPB

3.1M/IMX123(C)

1/2.8“ (5.12x3.84)

2.5x2.5

600mv with 1/30s

0.15mv with 1/30s

50@2048x1536

50@1920x1080

1x1

1x1

0.1ms~15s

E3ISPM02100KPA

2.1M/IMX482(C)

1/1.2”(11.14x6.26)

5.8x5.8

8935mv with 1/30s

0.6mv with 1/30s

96@1920x1080

1x1

14us~15s

E3ISPM02000KPA

2M/IMX385(C)

1/2“ (7.2x4.05)

3.75x3.75

2350mv with 1/30s

0.15mv with 1/30s

125@1920x1080

1x1

0.1ms~15s

E3ISPM01500KPA

1.5M/IMX273(C, GS)

1/2.9“ (4.968x3.726)

3.45x3.45

1146mv with 1/30s

0.15mv with 1/30s

164@1440x1080

320@720x540

1x1

2x2

0.1ms~15s
